Bitspower DDC Reservoir Combo 150 Acrylic-PWM

Bitspower DDC Reservoir Combo 150 Acrylic-PWM

Product Code : BP-DDCPLSR150AC-PWM

寸法 ( ΦxH ) : 60X219 MM. ( +/-3%)

Pump Specification:
Max. flow : 9.6 LPM
Max. head : 4.34 M
Rated voltage : 12V DC
Rated Current : 1.33A
Power consumption : 16W
Noise level : ≦40dBA
Max. temperature : 70℃

リザーバー部分のスペック

1. DDC Pump Top Reservoir.
2. Easy Installation With 150 MM Tube Reservoir.
3. 2017 Refresh Design.
4. Made of Hi-Quality Acrylic.
5. Made of Hi-Quality Aluminum Abrasive Black Pump Case For Excellent Heat Dissipation.
6. RoHS Compliant.

寸法 ( ΦxH ) : 60X186 MM. ( +/-3%)
Color : Clear
Thread : G1/4” x 5

ヒートシンク底のブラケット固定穴がBykski 120mm Multi Function 90 Degree Shelf Style Water Cooling Bracket / B-PMFSに対応しています。
